TP-Link TL-SG108PE Smart Managed Desktop PoE 8 Port Gigabit Switch
£76.66 inc.VAT / £63.88 exc.VAT
TP-Link TL-SG108PE Easy Smart 8-Port Smart Managed Desktop Gigabit PoE Switch (55W)
TP-Link TL-SG108PE Smart Managed Desktop PoE 8 Port Gigabit Switch represents a powerful upgrade from an unmanaged switch.
Out of stock
TP-Link TL-SG108PE Easy Smart 8-Port Smart Managed Desktop Gigabit PoE Switch (55W)
TP-Link TL-SG108PE Smart Managed Desktop PoE 8 Port Gigabit Switch
TP-Link TL-SG108PE Smart Managed Desktop PoE 8 Port Gigabit Switch represents a powerful upgrade from an unmanaged switch. It is designed specifically for small businesses that require simple network management and PoE function.
The TP-Link TL-SG108PE can connect and power up to four (4) PoE devices, such as wireless access points (APs), IP cameras, and IP phones. Through its web-based user interface and management utility, the TP-Link TL-SG108PE offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.
Gigabit Switch TL-SG108PE Smart Managed Desktop PoE 8 Port
Key Features
- Eight (8) 10/100/1000 Gigabit Ethernet RJ45 ports.
- Four (4) PoE ports, so data and power can be transferred on one single cable.
- Provides network monitoring, traffic prioritization and VLAN features.
- Simple network set-up on top of plug-and-play connectivity.
- Web-based user interface and Easy Smart Configuration Utility simplify configuration.
Power Over Ethernet
Four (4) of the Auto-Negotiation RJ45 ports (port 1 to port 4) support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs). The maximum PoE budget for this switch is 55 Watts, with a port maximum of 15.4W per port.
Effective Management
The TP-Link TL-SG108PE offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, this switch offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.
With Port Mirroring, Loop Prevention and Cable Diagnostics features, the TP-Link TL-SG108PE can identify and even locate connection problems on your business network.
QoS
Administrators can designate the priority of the traffic based on Port Priority, 802.1P Priority and DSCP Priority, to ensure that voice and video are always clear, smooth and lag-free. Additionally, to improve security and network performance, the TP-Link TL-SG108PE supports MTU VLAN, port-based VLAN and 802.1Q-based VLAN functions. The TP-Link TL-SG108PE is an upgrade from a plug-and-play unmanaged switch, delivering great value while empowering your network and similarly delivering great value to the end user.
IGMP Snooping
IGMP Snooping optimises multimedia traffic delivery, to ensure a better network experience especially for applications like IPTV.
Easy to Use
Auto MDI/MDI-X crossover on all ports eliminates the need for crossover cables and uplink ports. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adapts to promote compatibility and optimize performance.
The convenient, compact size makes this switch ideal for desktops with limited space. Active LED indicators provide real-time status feedback and basic error diagnostics.
Sturdy metal casing
The TP-Link TL-SG108PE features sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. In addition, its fanless design ensures quiet operation.
Specifications
Hardware Features
Standards and Protocols
- IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
InterfaceÂ
- 8 x 10/100/1000Mbps RJ45 Ports
- AUTO Negotiation/AUTO MDI/MDIX
Network Media
- 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
- EIA/TIA-568 100 ohms STP (maximum 100m)
- 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
- EIA/TIA-568 100 ohms STP (maximum 100m)
- 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
- EIA/TIA-568 100 ohms STP (maximum 100m)
Fan Quantity
- Fanless
Power Supply
- External Power Adapter(Output: 48VDC / 1.25A)
Power Consumption
- Maximum (PoE on): 65.2W (220V/50Hz)
- Maximum (PoE off): 5.2W (220V/50Hz)
PoE+ Ports(RJ45)
- Standard: 802.3 af compliant
- PoE Ports: Port 1- Port 4
- PoE Power Budget: 55W
Performance
Packet Forwarding Rate
- 11.9Mpps
MAC Address Table
- 4K
Packet Buffer Memory
- 1.5Mb
Jumbo Frame
- 15KB
Software Features
Quality of Service
- Support Port-Based/802.1p/DSCP priority
- Support 4 priority queues
- Rate Limit
- Storm Control
L2 Features
- IGMP Snooping
- Link Aggregation
- Port Mirroring
- Cable Diagnostics
- Loop Prevention
VLANÂ
- Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
- MTU/Port/Tag VLAN
ManagementÂ
- Web-based GUI
- Easy Smart Configuration Utility
Transmission Method
- Store-And-Forward
Others
CertificationÂ
- FCC
- CE
- RoHS
System Requirements
- Microsoft Windows for running Utility
EnvironmentÂ
- Operating Temperature: 0°C~40°C (32°F~104°F)
- Storage Temperature: -40°C~70°C (-40°F~158°F)
- Operating Humidity: 10%~90%RH non-condensing
- Storage Humidity: 5%~95%RH non-condensing
Package Contents
- TL-SG108PE
- Power Adapter
- Installation Guide
- Resource CD
- Set of Rubber Feet
Standard Warranty: 3-Years
