Ubiquiti UFiber WiFi6 GPON CPE (UF WiFi6)
£114.46 inc.VAT / £95.38 exc.VAT
Ubiquiti UFiber WiFi6 – 4-Port GPON Router with Wi-Fi (UF-WiFi6)
(This item gets Dispatch with in 3 to 5 Days of order)
Ubiquiti UFiber WiFi6 GPON CPE (UF WiFi6) is a point-to-multipoint WiFi 6 device for build high-speed GPON connections.
Ubiquiti UFiber WiFi6 – 4-Port GPON Router with Wi-Fi (UF-WiFi6)
Ubiquiti UFiber WiFi6 GPON CPE (UF WiFi6)
Ubiquiti UFiber WiFi 6 GPON CPE (UF WiFi6) is a point-to-multi point WiFi 6 device that can build high-speed GPON connections with a downstream rate of 2.4 Gbps and an upstream rate of 1.2 Gbps.
To connect a local fibre connection, the UF WiFi6 features four GbE RJ45 LAN connectors and one GPON WAN port.
It also excels at building dependable, long-distance fibre links of up to 20 kilo meters, allowing you to extend your service area and customer base.
Key Features
- 2×2, high-efficiency WiFi 6
- 2.4 GHz band (2×2 MIMO) with a 300 Mbps radio rate
- 5 GHz band (2×2 MU-MIMO and OFDMA) with a 1.2 Gbps radio rate
- 2.4 Gbps max downstream line rate
- 1.2 Gbps max upstream line rate
- Establishes GPON links up to 20 km
- Powerful Layer 2/3 management features
- (1) GPON WAN port
- (4) GbE RJ45 LAN ports
- Powered with the included power adapter or passive PoE
- Internal WiFi 6 (802.11ax) antennas
Specifications
Mechanical
- Dimensions: 140.8 x 141.5 x 31.65 mm (5.54 x 5.57 x 1.25″)
- Weight: 415 g (0.99 lb)
- Enclosure material: UV-stabilized polycarbonate
Hardware
- Processor: Dual-core MIPS 1004 Kc at 900 MHz
- Memory: 256 MB RAM
- Total non-blocking line rate: 2.488 Gbps downstream
- 1.244 Gbps upstream
- Networking interfaces: (1) SC/APC, ITU-G.984 GPON WAN port, (4) GbE RJ45 LAN ports, WiFi 802.11ax 5/2.4 GHz channels
- PoE interface: (1) PoE in, 24V passive PoE
- Management interface: Ethernet in-band, PON
- Button: Factory-reset
- Max. power consumption: 11W
- Power method: USB-C 5VDC, 3A, 24V passive PoE, 0.5A
- Power supply: 5VDC, 3A power adapter, 1.5 m cord (included)
- Passive PoE 2-pair (4, 5+; 7, 8-)
- Supported voltage range: 10 to 30VDC passive PoE, 5VDC adapter
- Normal TX range of optical module: 0.5 to 5 dBm
- Normal RX range of optical module: -8 to -28 dBm
- Operating temperature: -15 to 45° C (5 to 113° F)
- Operating humidity: 10 to 90% noncondensing
- Certifications: FCC, IC, CE
Max. WiFi TX Power
- 2.4 Ghz: 2 x 2
- 5 Ghz: 2 x 2
Max. WiFi radio rate
- 2.4 Ghz: 300 Mbps
- 5 Ghz: 1.2 Gbps
Antenna Gain
- 2.4 GHz: 1 dBi
- 5 GHz: 3 dBi
Software
- Mode: ONU/ONT layer 2/3 Ethernet switch
- Services: Web server, telnet, NAT, bridging and routing, firewall features, and application passthrough features
- Utilities: Dashboard, monitoring, alarms, and logs
- Other: Remote reset, remote reboot, remote firmware upgrade, VLAN support
- Security: GEM Port Encryption
- Ubiquiti specific features: UBNT Discovery and UISP Mobile app
- WiFi standards: 802.11 b/g, WiFi 4/WiFi 5/WiFi 6
- Wireless security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3, TKIP/AES)
- Minimum software requirements: Any modern web browser (Google Chrome™ recommended)
Fiber
- Operating wavelength: 1310 nm TX/1490 nm RX
- Optical interface downstream nominal bit rate: 2488.32 Mbit/s
- Optical interface upstream nominal bit rate: 1244.16 Mbit/s
- Physical reach: 20 km
Supported Data Rates
- 802.11b 1, 2, 5.5, 11 Mbps
- 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n (WiFi 4) 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
- 802.11ac (WiFi 5) 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
- 802.11ax (WiFi 6) 8.6 Mbps to 1.2 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80)
