Ubiquiti UniFi LED Dimmer (UDIM-AT)
£64.97 inc.VAT / £54.14 exc.VAT
Ubiquiti UniFi LED Dimmer (UDIM-AT)
               (This item gets Dispatch with in 3 to 5 Days of order)
Ubiquiti UniFi LED Dimmer (UDIM-AT) is a smart in-wall dimmer switch for use with the UniFi LED Lighting System.
Ubiquiti UniFi LED Dimmer (UDIM-AT)
Ubiquiti UniFi LED Dimmer (UDIM-AT) is a smart in-wall dimmer switch for use with the UniFi LED Lighting System.
Powered by PoE, the UDIM-AT is designed to fit in an electrical switch box and networked by Ethernet.
Use the intuitive UniFi LED App and EoT Controller to configure the UDIM-AT to control a defined group of UniFi LED Lights.
Key Features
- Powered by 802.3af PoE
- Configured and managed by UniFi LED App and UniFi LED Controller
- For use with the UniFi LED Lighting System
- Configure and control multiple UniFi LED Lights
- Physical On/Off and dimming features
- Fits 1-Gang In-Wall Electrical Box
Hardware Overview
The UniFi LED Panel and UniFi Dimmer Switch can be deployed in a variety of environments, including commercial office buildings, schools, and hospitals. Both require only Ethernet cabling to receive power and connect to the network.
Specification
General
- Dimensions: 71 x 115 x 25 mm (2.8 x 4.53 x 0.98″)
- Weight: 90 g (3.2 oz)
- Management Interface: UniFi LED Controller/ UniFi LED App
- Networking Interface: 10/100 Ethernet Port
- Buttons: Reset
- LEDs: Status
- Power Method: 802.3af PoE
- Power Supply: UniFi Switch (802.3af)
- Supported Voltage Range: 48V
- Maximum Power Consumption: 5W
- Max. LED Panels per Dimmer Switch: 128 (Recommended)
- Operating Temperature: 10 to 40° C (50 to 104° F)
- Operating Humidity: 10 to 90% Noncondensing
- Certifications: CE, FCC, IC
UniFi LED Controller – Software
- Platforms: UniFi Application Server 0.5.0, Ubuntu 16.04 LTS (Xenial Serus) 64-bit, Debian 9 64-bit
- Minimum Memory Requirement:
- RAM: 2GB
- Storage 16GB
- CPU: 64-bit (x64)
- Features:
- Control: On/Off, Brightness, Locating, Grouping
- Monitoring: Device Status, Power Usage, Up Time, Light Up Time, Energy Statistics
- Management: Reboot, Factory Reset, Forget Device
- Filters: LED Panels, Dimmer Switches
- Scheduling: On/Off Times, Brightness, One-time/Recurring
- Management Interface: Web UI
UniFi LED App – Software
- OS: iOS, Android
- Features:
- Control: On/Off, Brightness, Locating, Grouping
- Monitoring: Device Status, Power Usage, Up Time, Light Up Time, Energy Statistics
- Management: Reboot, Factory Reset, Forget Device
- Filters: LED Panels, Dimmer Switches
Ubiquiti UniFi Switch Compatibility
- Ubiquiti UniFi Switches that are compatible with the UDIM-AT:
- US-8
- US-8-60W
- US-8-150W
- US-16-150W
- US-24-250W
- US-24-500W
- US-48-500W
- US-48-750W
