TP-Link TL-SF1008LP 8-Port Unmanaged Desktop Fast Ethernet Switch w/ 4 x PoE Ports (41W)

TP-Link TL-SF1008LP Unmanaged Desktop PoE 8 Port Ethernet Switch

TP-Link TL-SF1008LP Unmanaged Desktop PoE 8 Port Ethernet Switch requires no configuration and provides four (4) PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs).

In this situation, the electrical power is transmitted along with data in one single cable, allowing you to expand your network and fix devices such as APs, IP Cameras or IP Phones to places where there are no power lines or outlets.

Unmanaged Desktop TL-SF1008LP PoE 8 Port Ethernet Switch

Key Features

• Eight (8) 10/100 Mbps RJ45 ports.
• Four (4) PoE ports to transfer data and power on one single cable.
• Works with IEEE 802.3af compliant PDs to expand your network.
• Supports PoE power up to 15.4 W for each PoE port, with a total budget of 41W.
• Up to 250 m data and power transmission under Extend Mode.
• Priority Mode ensures high priority of port 1–2 to guarantee the quality of sensitive application.
• Requires no configuration and installation.

Dedicated 4-Ports PoE

Compliance with the 802.3af PoE standard supports up to 15.4 W on each PoE port. The total 41 W PoE power budget for the four (4) PoE ports (port 1 to port 4) opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Overload Arrangement

The TL-SF1008LP has a priority function which will help protect the system when the system power is overloaded. If all PoE PDs’ power consumption is > 41 W, a priority will be arranged among the PoE ports and the system will cut off the power of the lowest-priority port.

Intelligent Power Management

Priority (port 1 = port 2 = port 3 > port 4): This function will help protect the system when the system power is overloaded. For example, ports 1, 2 and 4 are using 12 W (maximum power per port is 15.4 W); the system power is 36 W in total. If there is an additional PD inserted to port 3 with 12 W and the system then cuts off the power of port 4 because of the overloaded power, this means ports 1, 2, and 3 will use 12 W and no power will be supplied to port 4.

Easy to Use

The TL-SF1008LP is easy to install and use. It requires no configuration and installation. With a desktop and wall-mountable design, plus outstanding performance and quality, this TP-Link 8-Port 10/100Mbps desktop switch is a great choice for expanding your network.

Ideal for IP Surveillance

With Extend Mode enabled, the PoE transmission distance can reach up to 250 m — perfect for IP Camera deployment in large areas.

Priority Video Quality Guaranteed

The quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.

Intelligent Power Management

When total power consumption exceeds 41 W, the intelligent power management will cut the lower priority port’s power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

Durable Metal Casing

The interior components of the TL-SF1008LP are protected by a high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, the TL-SF1008LP delivers switching performance you can depend on.

Specifications

Standard Warranty: Limited Lifetime
