NETGEAR XS508M 8-Port Unmanaged 10 Gigabit Switch
£518.92 inc.VAT / £432.43 exc.VAT
NETGEAR XS508M 8-Port Unmanaged 10 Rackmount Gigabit Switch w/ 1 x SFP+ Port
NETGEAR XS508M 8-Port Unmanaged 10 Gigabit Switch comes with Copper Ethernet ports that provide either Fast Ethernet, 1-Gigabit, 2.5-Gigabit, 5-Gigabit or 10-Gigabit connectivity.
NETGEAR XS508M 8-Port Unmanaged 10 Rackmount Gigabit Switch w/ 1 x SFP+ Port
NETGEAR XS508M 8-Port Unmanaged 10 Gigabit Switch
NETGEAR XS508M 8-Port Unmanaged 10 Gigabit Switch comes with Copper Ethernet ports that provide either Fast Ethernet, 1-Gigabit, 2.5-Gigabit, 5-Gigabit or 10-Gigabit connectivity, as well as 1 SFP+ Fiber port with 1 or 10-Gigabit connectivity.
Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to normal 10-Gigabit switches that will only provide 1-Gigabit connectivity to any devices that require less than 10-Gigabit, this new NETGEAR Multi-speed switch ports can be connected with standard Cat5E Ethernet cables, without the need to upgrade to Cat6 wiring, therefore reducing wiring costs and hassle.
10 Gigabit Switch XS508M 8-Port Unmanaged
Key Features
- 7x 10/100/1000/2.5G/5G/10 Gigabit RJ-45 copper ports.
- 1x 10G/1 Gigabit SFP+ and Copper combo ports.
- Simple set up with no software or configuration needed.
- Flexible mounting with Rackmount or Desktop mounting options.
- Made with a durable metal case and long product life.
- Automatically adjust power consumption according to the link status and cable length.
- Whisper-quiet switch with an active fan for quiet operation.
- 19-inch 1U design for Rackmounting.
Why the NETGEAR 10-Gig/Multi-Gig Switches are ideal for SMB
- Plug-and-play, automatic connectivity to your router or modem of 4 or 7 additional wired connections. No need for an IT expert!
- Expand your network instantly, and give your devices either 100Mb, 1, 2.5, 5 or 10-Gigabit, automatically.
- Small and silent desktop or rackmount form factor for quiet operation – Adapts to your needs and configuration in any environment.
- Energy efficient switches that automatically adjusts power consumption according to the link status and cable length.
Specifications
100M/1G/2.5G/5G/10G RJ-45 copper ports
- 7
10G SFP+ ports
- 1 x 10G/1G SFP+ and Copper (combo)
Form Factor
- Desktop/Rackmount
Performance Specification
Packet buffer memory (Dynamically shared across only used ports)
- 128KBMB
Forwarding modes
- Store-and-forward
Bandwidth
- 160Gbps
MAC Address database size (48-bit MAC addresses)
- 2K
Packet forwarding rate (64 byte packet size) (Mpps)
- 10Gbps: 14,880,952fps
- 5Gbps: 7,440,476fps
- 2500Mbps: 3,720,238fps
- 1000Mbps: 1,488,095fps
- 100Mbps: 148,810fps
Speed / Latency
- 100Mbps: <6µs
- 1Gbps: <4µs
- 2.5Gbps: TBD
- 5Gbps: TBD
- 10Gbps : TBD
Jumbo frame support
- Up to 9K packet size
Acoustic noise level @ 25°C (dBA) (ANSI-S10.12)
- 22.5
Mean Time Between Failures (MTBF) @ 25°C
- 1145157 hours
Power/Energy Efficiency
802.1p-based QoS/CoS Supported
- Yes
Auto Power Down
- Yes
Short Cable Detection/Power Saving
- Yes
Quality Of Service (QOS)
IEEE 802.3az (Energy Efficient Ethernet)
- Yes
Honors DSCP (DiffServ) Tags
- Yes
Weighted Round Robin (WRR)
- Yes
Priority Queues
- 8
IEEE Network Protocols
IEEE 802.3 Ethernet
- IEEE 802.3u 100BASE-TX
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3x Full-Duplex Flow Control
- IEEE 802.1p Class of Service
- IEEE 802.3az Energy Efficient Ethernet (EEE
- IEEE 802.3an 10GBASE-T
- IEEE 802.3bz 5Gbps and 2.5Gbps Ethernet Over Copper Twisted Pair Cable
- IEEE 802.3ae 10-Gigabit Ethernet Over Fibre
- IEEE 802.3aq 10-Gigabit over Fibre (10GBASE-LRM)
- IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
LEDS
Per port
- Speed, Link, Activity
Per device
- Power and Fan
Physical Specifications
Dimensions (W x D x H)
- 328 x 169 x 43.2 mm (12.91 x 6.65 x 1.7 in)
Weight
- 1.49kg
Power Consumption
Power Supply
- Fixed internal PSU, 100-240VAC, 50-60Hz, 1.5A max Power cord localized to country of sale
Max power (worst case, all ports used, line-rate traffic) (Watts)
- 39W
Min power (link-down standby) (Watts)
- 21.31
Heat Dissipation (max and min) (BTU/hr)
- 147.86/80.8
Fan(s)
- x1
Environmental Specifications
Operating
Operating temperature
- 0° to 50°C (32° to 122°F)
Humidity (relative)
- 95% maximum relative humidity (RH), non-condensing
Altitude
- 10,000 ft (3,000 m) maximum
Storage
Storage temperature
- –20° to 70°C (– 4° to 158°F)
Humidity (relative)
- 95% maximum relative humidity (RH), non-condensing
Altitude
- 10,000 ft (3,000 m) maximum
Electromagnetic Emissions and Immunity
Certifications
- 47 CFR FCC Part 15, SubpartB, ClassB
- ICES-003:2016 Issue 6, ClassB
- ANSI C63.4:2014
- EN 55022:2010 + AC:2011, Class A
- EN 55024:2010
- EN 61000-3-2:2014, Class A
- EN 6100-3-3:2013
- AS/NZS CISPR 22:2009 + A1:2010, Class B
- VCCI V-3/2015.04, Class A
- V-4/2012.4
- Russia EAC mark
- Korea KC mark
- CNS 13438
Electromagnetic Compliance (Class A or B)
- Class B
Safety Certifications
- CB mark, commercial
- IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013
- UL/cUL Listed (UL 60950-1)/CAN/CSA C22.2 No. 60960-1-07
- EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
- IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013
- AS/NZS 60950.1:2015
- Russia EAC mark
Package Contents
- XS508M 10-Gigabit Ethernet Unmanaged Switch
- Power cord
- Rack-mounting kit
- Quick install guide
Standard Warranty: Limited Lifetime
