NETGEAR MS510TXPP-100EUS 8 Port Desktop POE+ Gigabit Switch
£507.31 inc.VAT / £422.76 exc.VAT
NETGEAR MS510TXPP 8-Port Smart Managed Pro Desktop Gigabit PoE+ Switch (180W)
NETGEAR MS510TXPP-100EUS 8 Port Desktop POE+ Gigabit Switch with incoming new multispeed devices, their wired network needs to expand its reach and scope to support speeds greater than 1 Gigabit.
NETGEAR MS510TXPP 8-Port Smart Managed Pro Desktop Gigabit PoE+ Switch (180W)
NETGEAR MS510TXPP-100EUS 8 Port Desktop POE+ Gigabit Switch
NETGEAR MS510TXPP-100EUS 8 Port Desktop POE+ Gigabit Switch with incoming new multispeed devices, their wired network needs to expand its reach and scope to support speeds greater than 1 Gigabit.
The IEEE 802.3bz standard paved the way for new 2.5 Gigabit and 5 Gigabit speeds in addition to legacy 1 Gigabit and 10 Gigabit per second.
New servers, workstations, storage devices, and motherboards are coming with 802.3bz (NBASE-T) Multi-Gigabit Ethernet for 2.5X to 5X faster speeds up to 100 meters (323 feet) on legacy CAT5e / CAT6 cables.
That is why NETGEAR launched its new Multi-Gigabit Smart Managed Pro Switches with 10G Copper/Fiber Uplinks.
Gigabit Switch MS510TXPP-100EUS 8 Port Desktop POE+
Key Features
- 4x 10/100/1000 RJ-45 Gigabit Ethernet ports.
- 2x 100/1000/2500/5000G RJ-45 Multi-Gigabit Ethernet IEEE 802.3bz ports (NBASE-T).
- 2x 100/1000/2500 RJ-45 Multi-Gigabit Ethernet IEEE 802.3bz ports (NBASE-T).
- 1x SFP+ 1000/10,000 10 Gigabit Ethernet Fiber (BASE-X SFP+).
- 1x 100/1000/2500/5000/10,000 RJ-45 10 Gigabit Ethernet Copper (BASE-T).
- 1x SFP+ 1000/10,000 10 Gigabit Ethernet Fiber (BASE-X SFP+).
- 180W PoE budget available across 8 Gigabit and Multi-Gigabit PoE+ ports (802.3at).
- Fan-speed control with max 28.8dB at 25°C (77°F) ambient.
- Configure your network with the NETGEAR Smart Managed Pro Web GUI.
- Configurable L2 network features such as VLANs, Rapid Spanning Tree, IGMP Snooping and Querier.
- L2/L3/L4 access control lists (ACLs) for granular network access control including 802.1x port authentication
- Automatic VOIP prioritisation simplifies most complex multi-vendor IP telephone deployments.
The exact speed required
Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the Netgear MS510TXPP-100EUS 8-Port Smart Managed Pro Desktop Gigabit PoE+ Switch gives the exact speed required, with no downgrade.
Also, the new NETGEAR Multi-Gigabit switch ports can connect regular CAT5e Ethernet cables, without the need to upgrade to CAT6 wiring, therefore reducing wiring costs and hassle.
Access, Aggregation or Collapsed Core
You can now have your PCs, printers and routers/firewalls connected at 1G and aggregate Multi-Gigabit Ethernet new devices on the same switch, all line-rate. 10G copper and fiber ports are ready for local servers and storage, or high-speed aggregation to your network core.
Multi-Gigabit for Future-Proof Deployments
The Netgear MS510TXPP-100EUS 8-Port Smart Managed Pro Desktop Gigabit PoE+ Switch provides two Multi-Gigabit RJ-45 ports that support 5G, 2.5G, and 1G; another two Multi-Gigabit RJ-45 ports that support 2.5G and 1G; four 1G RJ-45 ports; one dedicated 10G RJ-45 uplink port (which also supports 5G, 2.5G and 1G); and one dedicated SFP+ fiber uplink port that supports 10G and 1G.
Comprehensive L2+/Layer 3 Lite Features
The Netgear MS510TXPP-100EUS 8-Port Smart Managed Pro Desktop Gigabit PoE+ Switch offers powerful L2+ and Layer 3 Lite features, enhanced performance and usability. They are purposely designed for converged networks where voice, video, data are all carried on a single network platform.
These switches are optimized for network efficiency, operational cost savings, and ease of management. Advanced features such as IPv4/IPv6 Layer 3 static routing, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks.
Smart IT, not Big IT
No need for an IT expert or a complicated user manual, just configure your network with the user-friendly NETGEAR Smart Managed Pro Web browser-based management GUI. The Netgear MS510TXPP-100EUS 8-Port Smart Managed Pro Desktop Gigabit PoE+ Switch is backed by NETGEAR ProSAFE Lifetime Limited Warranty and 24/7 support including lifetime chat.
Specifications
10M/100M/1G RJ-45 copper ports
- 4
100M/1G/2.5G RJ-45 copper ports
- 2
100M/1G/2.5G/5G RJ-45 copper ports
- 2
100M/1G/2.5G/5G/10G RJ-45 copper ports 1 (dedicated)
- 1 (dedicated)
1G/10G SFP+ (fiber) ports 1 (dedicated)
- 1 (dedicated)
USB port (for config file upload/backup & firmware updates)
- Yes
PERFORMANCE SPECIFICATION
Packet buffer memory (Dynamically shared across only used ports)
- 1.5 MB
Forwarding modes
- Store-and-forward
Bandwidth
- 78Gbps
1G Copper Latency (64 byte packet size)
- <2.60 µs
2.5G Copper Latency (64 byte packet size)
- <19.42 µs
5G Copper Latency (64 byte packet size)
- <13.4 µs
10G Copper Latency (64 byte packet size)
- <2.36 µs
10G Fiber Latency (64 byte packet size)
- <2.61 µs
Priority queues
- 8
Priority queuing
- Weighted Round Robin (WRR) and Strict Priority
MAC Address database size (48-bit MAC addresses)
- 16K
Multicast groups
- 512
Number of IPv4 static routes
- 32
Number of IPv6 static routes
- 32
Number of VLANs
- 256
Number of ARP cache entries
- 512
Number of DHCP snooping bindings
- 1K
Access Control Lists (ACLs)
- 164 shared for MAC, IP and IPv6 ACLs
Packet forwarding rate (64 byte packet size)(Mfps or Mbps)
- 58
Jumbo frame support
- Up to 10K packet size
Acoustic noise level @ 25°C (dBA) (ANSI-S10.12)
- 28.8 dBA
Mean Time Between Failures (MTBF) @ 25°C
- 376,434 hours
L2 SERVICES – VLANS
IEEE 802.1Q VLAN tagging
- Yes
IP-based VLANs
- Yes
MAC-based VLANs
- Yes
Auto-VoIP VLAN / Auto-Voice VLAN
- Yes, based on OUI bytes (default database and user-based OUIs) in the phone source MAC address, voice packets must have 802.1Q VLAN tag
Auto-VoIP
- Yes, based on protocols (SIP, H.323 and SCCP). Prioritizes traffic to a higher queue
Voice VLAN
- Yes
Auto-Video VLAN
- Yes
Private VLAN
- Yes
L2 SERVICES – AVAILABILITY
Broadcast, multicast, unknown unicast storm control
- Yes
IEEE 802.3ad – LAGs (LACP)
- Yes
IEEE 802.3x (full duplex and flow control)
- Yes
IEEE 802.1D Spanning Tree Protocol
- Yes
IEEE 802.1w Rapid Spanning Tree Protocol
- Yes
IEEE 802.1s Multiple Spanning Tree Protocol
- Yes
L2 SERVICES – MULTICAST FILTERING
IGMP snooping (v1, v2 and v3)
- Yes
MLD snooping support (v1 and v2)
- Yes
IGMP snooping queries
- Yes
Block unknown multicast
- Yes
L3 SERVICES – DHCP
DHCP client
- Yes
DHCP snooping
- Yes
L3 SERVICES – ROUTING
IPv4 static routing
- 32
IPv6 static routing
- 32
VLAN routing
- Yes
Host ARP table (number of entries)
- 512
Number of IP VLAN interfaces (routed VLANs)
- 32
LINK AGGREGATION
IEEE 802.3ad – LAGs (LACP)
- Yes
Manual Static LAG
- Yes
Number of Static or LACP LAGs and members in each LAG
- 8 LAGs with max 8 members in each LAG
NETWORK MONITORING AND DISCOVERY SERVICES
802.1ab LLDP
- Yes
SNMP
- v1
- v2c
- v3
RMON group 1,2,3,9
- Yes
NETWORK SECURITY
IEEE 802.1x
- Yes
Guest VLAN
- Yes
RADIUS-based VLAN assignment via .1x
- Yes
MAC-based .1x
- Yes
RADIUS accounting
- Yes
Access Control Lists (ACLs)
- L2 / L3 / L4 ingress
IP-based ACLs (IPv4 and IPv6)
- Yes
MAC-based ACLs
- Yes
TCP/UPD-based ACLs
- Yes
MAC lockdown
- Yes
MAC lockdown by the number of MACs
- Yes
Control MAC # Dynamic learned entries
- 600
Control MAC # static entries
- 600
IEEE 802.1x RADIUS port access authentication
- Yes
Port-based security by locked MAC addresses
- Yes
Dynamic ARP inspection
- Yes
Broadcast, multicast, unknown unicast storm control
- Yes
DoS attacks prevention
- Yes
QUALITY OF SERVICE (QOS)
Port-based rate limiting
- Ingress and egress
Port-based QoS
- Yes
Support for IPv6 fields
- Yes
DiffServ QoS
- Yes
IEEE 802.1p COS
- Yes
Destination MAC and IP
- Yes
IPv4 and v6 DSCP
- Yes
IPv4 and IPv6 ToS
- Yes
TCP/UDP-based
- Yes
Weighted Round Robin (WRR)
- Yes
Strict priority queue technology
- Yes
Auto-VoIP VLAN / Auto-Voice VLAN
- Yes, based on OUI bytes (default database and user- based OUIs) in the phone source MAC address, voice packets must have 802.1Q VLAN tag
Auto-VoIP
- Yes, based on protocols (SIP, H.323 and SCCP). Prioritizes traffic to a higher queue
Voice VLAN
- Yes
Auto-Video VLAN
- Yes
IEEE NETWORK PROTOCOLS
- IEEE 802.3 Ethernet
- IEEE 802.3u 100BASE-T
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3an 10GBASE-T 10Gbps Ethernet Over Copper Twisted Pair Cable
- IEEE 802.3ae 10-Gigabit Ethernet Over Fiber (10GBASE-SR, 10GBASE-LR, 10GBASE-ER, 10GBASE-LX4) – All models
- IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
- IEEE 802.3x Full-Duplex Flow Control
- IEEE 802.1Q VLAN Tagging
- IEEE 802.3ad Trunking (LACP)
- IEEE 802.1AB LLDP with ANSI/TIA-1057 (LLDP-MED)
- IEEE 802.1p Class of Service
- IEEE 802.1D Spanning Tree (STP)
- IEEE 802.1s Multiple Spanning Tree (MSTP)
- IEEE 802.1w Rapid Spanning Tree (RSTP)
- IEEE 802.1x RADIUS Network Access Control
- IEEE 802.3az Energy Efficient Ethernet (EEE)
MANAGEMENTPassword management
- Yes
Configurable management VLAN
- Yes
Admin access control via RADIUS and TACACS+
- Yes
IPv6 management
- Yes
SNTP client over UDP port 123
- Yes
SNMP v1/v2c
- Yes
SNMP v3 with multiple IP addresses
- Yes
RMON group 1,2,3,9
- Yes
Port mirroring
- Yes
Many-to-one port mirroring
- 8
Web browser-based graphical user interface (GUI)
- Yes
Smart Control Center (SCC) for multi-switch management
- Yes
Dual software (firmware) image
- Yes
Dual configuration file
- Yes
Cable test utility
- Yes
SSL/HTTPS Web-based access (version)
- Yes (v2)
TLS Web-based access (version)
- Yes (v1.0 ~ v1.2)
File transfers (uploads, downloads)
- TFTP / HTTP
HTTP upload/download (firmware)
- Yes
Syslog (RFC 3164)
- Yes
USB port for firmware and config upload / download
- Yes
LEDS
Per port
- Speed
- Link
- Activity
- PoE Mode
Per device
- Power
- Fan
- Max PoE
PHYSICAL SPECIFICATIONS
Dimensions (W x D x H)
- 328 x 169 x 43 mm (12.9 x 6.7 x 1.7 in)
Weight
- 1.9 kg (4.9 lb)
POWER CONSUMPTION
Max power (worst case, all ports used, line-rate traffic) (Watts)
- 234.31 W
Min power (link-down standby) (Watts)
- 19.39 W W
Heat Dissipation (max and min) (BTU/hr)
- Max: 799.50 BTU/hr
- Min: 66.16 BTU/hr
Energy Efficient Ethernet (EEE) IEEE 802.3az
- Yes (deactivated by default)
Power back-off
- Drops power consumption by 15% to 20% when short copper cables are detected
Auto power down
- Drops power consumption when no connection
Fan
- 1
ENVIRONMENTAL SPECIFICATIONS
Operating
Operating temperature
- 0° to 50°C (32° to 122°F)
Humidity (relative)
- 90% maximum relative humidity (RH), non-condensing
Altitude
- 10,000ft (3,000m) maximum
Storage
Storage temperature
- –20° to 70°C (– 4° to 158°F)
Humidity (relative)
- 95% maximum relative humidity, non-condensing
Altitude
- 10,000ft (3,000m) maximum
ELECTROMAGNETIC EMISSIONS AND IMMUNITY
Certifications
- CE: EN 55032:2012+AC:2013/CISPR 32:2012, EN 61000-3-2:2014, Class A, EN 61000-3-3:2013, EN 55024:2010
- VCCI : VCCI-CISPR 32:2016, Class A
- RCM: AS/NZS CISPR 32:2013 Class A
- CCC: GB4943.1-2011; YD/T993-1998; GB/T9254-2008 (Class A)
- FCC: 47 CFR FCC Part 15, Class A, ANSI C63.4:2014
- ISED: ICES-003:2016 Issue 6, Class A, ANSI C63.4:2014
- BSMI: CNS 13438 Class A
SAFETY
Certifications
- CB report / certificate IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013
- UL listed (UL 1950)/cUL IEC 950/EN 60950
- CE LVD: EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
- RCM (AS/NZS) 60950.1:2015
- CCC (China Compulsory Certificate): GB4943.1-2011; YD/T993-1998; GB/T9254-2008 (Class A)
- BSMI: CNS 14336-1
Standard Warranty: Limited Lifetime
Only logged in customers who have purchased this product may leave a review.
Related Products
TP-Link TL-SG3210 JetStream 8-Port Layer 2+ Managed Gigabit Switch w/ 2 x 1G SFP Slots
The TP-Link TL-SG3210 JetStream 8-Port L2+ Managed Gigabit Ethernet Switch provides high performance, powerful L2 and L2+ features like static routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The IP-MAC-Port Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-ofService (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM and DDM functions help facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link JetStream L2/L2+ managed Switches provide a reliable, secure solution for enterprise, campus and ISP networks.
Out of stock
Ubiquiti UISP Gigabit PoE Switch for MicroPoP Applications (UISP-S)
                 ( 2 in Stock – Available for next day shipment )Â
UISP Switch is a fan-less Layer 2 PoE switch with (8) GbE RJ45 ports and (1) 1G SFP port for an additional fiber uplink option, making it ideal for wireless ISP (WISP) deployments.
2 in stock
TP-Link LS1008G LiteWave 8-Port Unmanaged Desktop Gigabit Switch (10/100/1000Mbps)
TP-Link LS1008G LiteWave 8-Port Unmanaged Gigabit Switch provides an easy and affordable way to expand your wired network.
Out of stock
TP-LINK TL-SG108 8-Port Desktop Gigabit Switch (10/100/1000 Mb/s)
TP-LINK TL-SG108 8 Port Desktop Gigabit Switch provides you an easy way to make the transition to Gigabit Ethernet.
Out of stock
Ubiquiti USW-Enterprise-8-PoE UniFi 8-Port Layer 3 Managed Desktop 2.5-Gigabit PoE+ Switch w/ 2 x 10GbE SFP+ Ports (120W)
Ubiquiti USW-Enterprise-8-PoE UniFi 8-Port Layer 3 Managed Desktop 2.5-Gigabit PoE+ Switch allows you to build and expand your network.
132 in stock
TP-Link TL-SG3452 JetStream 48-Port Smart Managed Rackmount Gigabit Switch w/ 4 x 1G SFP Ports
The TP-Link TL-SG3452 JetStream 48-Port Layer 2 Managed Rackmount Gigabit Switch provides reliable gigabit connections with forty-eight (48) RJ45 ports and four (4) SFP ports. With Omada, you can manage and maintain your TL-SG3452 switch using this Centralised Cloud Management SDN solution to make your network as efficient as it can be. The advanced Layer 2+ features include L2/L3/L4 QoS, ACL, Static Routing and more, along with an abundance of security strategies, such as LAN Area Investment Protection.
Out of stock
Ubiquiti ES-10X Edge Switch 8-Port Managed Passive PoE Gigabit Switch w/ 2 x 1GbE SFP Ports (52W)Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
The Ubiquiti ES-10X Edge Switch Managed Passive PoE 8-Port Gigabit Switch is an affordable managed 8-port switch with two additional SFP ports, and is ideal for WISP applications. This switch has eight Gigabit RJ45 ports that offer copper connectivity with PoE input on port 1 and PoE pass through on port 8, as well as two SFP ports providing fibre connectivity. The browser-based configuration interface offers intuitive control using a redesigned UI. Management is also available through the Ubiquiti Network Management System (UNMS).
Out of stock
NETGEAR GS108 ProSAFE 8-Port Gigabit Switch
Now you can have a powerful, high-speed network on a small scale. Netgear’s GS108 Gigabit Ethernet Switch lets you build a system that provides a full, dedicated 1000, 100, or 10 Mbps connection so you can move very large files across your network instantly. The Netgear GS108 also lets you painlessly integrate 10, 100, and 1000 Mbps devices. The Netgear GS108 is a potent switch packed with ease-of-use features to simplify your workday experience. The Netgear’s GS108 compact design fits neatly into small work spaces and, since it’s self-cooling without a fan, it runs silently and unobtrusively.
984 in stock
TP-Link TL-SG1008MP 8-Port Unmanaged Rackmount Gigabit PoE+ Switch (126W)
The TP-Link TL-SG1008MP 8-Port Unmanaged Gigabit PoE+ Switch supports the PoE+ standard on all ports. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 126W and up to 30W per port, the TL-SG1008MP can power more high-powered devices such as wireless access points (APs), IP cameras or IP phones. Moreover, with innovative energy-efficient technology, the TL-SG1008MP can save up to 75% of the power consumption, making it an eco-friendly solution for your business network.
Out of stock
DrayTek G1085 VigorSwitch 8-Port Cloud Managed Rackmount Gigabit Switch
The DrayTek G1085 VigorSwitch 8-Port Cloud Managed Rackmount Gigabit Switch is ideal for adding network ports to a DrayTek Vigor router (sold separately), implementing complex networks with VLANs and adding port-level security with the switch’s Access Control List. Designed for centralised management, the VigorSwitch G1085 can be provisioned and monitored with the VigorACS management platform, the free VigorConnect single site management system and/or with a DrayTek Vigor router’s Central Switch Management. Easily provision VLAN configuration through the router and clone switch configurations. Drastically reduce the setup time required for a complex network and configure an entire DrayTek network remotely.
22 in stock
TP-Link TL-SG1008D 8-Port Unmanaged Desktop Gigabit Switch
TP-LINK TL-SG1008D 8 Port Gigabit Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve.
Out of stock
Ubiquiti USW-Aggregation UniFi 8-Port Layer 2 Managed Rackmount 10-Gigabit SFP+ Switch
The Ubiquiti USW-Aggregation 8-Port Layer 2 Managed Rackmount 10-Gigabit SFP+ Switch offers link aggregation for higher capacity and increased availability. The USW-Aggregation switch features Layer 2 capabilities and supports high bandwidth links, making it ideal for aggregation switching to any UniFi solution that deploys various interconnect topologies. Its built-in 36W AC/DC power supply can support copper Ethernet UF-RJ45-10G modules (sold separately ) in all eight ports.
14 in stock
Reviews
There are no reviews yet.
