Specifications
Features
10/100/1000 RJ45 Copper Ports (Auto Uplink)
- 8
Enclosure
- Metal
Connector Type
- Metal
PoE
Number of PoE ports
- 8
Number of PoE+ 802.3at Ports
- 8
Total PoE/PoE+ Budget
- 62W
Uninterrupted PoE
- Yes
Performance Specification
Forwarding modes
- Store-and-forward
Bandwidth
- 16Gbps
Max MAC entries
- 4K
Buffer Size
- 192KB
Energy Efficient Ethernet (IEEE 802.3az) compliant
- Yes
Priority queuing
- WRR
Jumbo frame support
- 9,216 bytes
Acoustic noise level @ 25ºC (dBA)(ANSI-S10.12)
- 0
Mean Time Between Failures (MTBF) @ 25ºC
- 859,126 hours
L2 Services – VLANS
VLAN (Number Supported)
- 64
IEEE 802.1Q VLAN Tagging
- Yes
Port-based VLANs
- Yes
L2 Services – Availability
Link Aggregation/Port Trunking
- Yes
Number of Static Manual LAGs/Number of members
- 2/4
L2 Services – Multicasting Filtering
IGMP snooping (v1, v2, and v3)
- Yes
Block unknown multicast
- Yes
Supported Multicast groups
- 128
L3 Services – DHCP
DHCP client
- Yes
Quality of Service
Rate Limiting
- Yes
DSCP
- Yes
IEEE 802.1p COS
- Yes
Port-based VLAN
- Yes
WRR (Weighted Round Robin)
- Yes
Strict Priority queue technology
- No
Protocols
IEEE Network Protocols
- IEEE 802.3 Ethernet
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3u 100BASE-T
- IEEE 802.3ab 1000BASE-T
- IEEE 802.1p Class of Service
- IEEE 802.1Q VLAN Tagging
- IEEE 802.3x Full-duplex Flow Control
- IEEE 802.3af PoE
- IEEE 802.3at PoE+
Management
System Password
- Yes
Web browser based management GUI
- Yes
PC Utility
- No
One-to-one Port Mirroring
- Yes
Cable Test Utility
- Yes
Config upload (to server)
- Yes
LEDs
Per port
- Speed, Link, Activity, PoE
Per device
- Power, system, PoE Max
Physical Specifications
Dimensions (W x D x H)
- 158 x 101 x 27 mm (6.2 x 4.0 x 1.1 in.)
Weight
- 0.49 kg (1.08 lb.)
Environmental Specifications
Operating temperature
- 0ºC to 40ºC (32ºF to 104ºF)
Operating humidity (relative)
- 90% maximum relative humidity (RH), non-condensing
Operating altitude
- 10,000 ft (3,000 m) maximum
Storage temperature
- –20ºC to 70ºC (– 4ºF to 158ºF)
Storage humidity (relative)
- 95% maximum relative humidity (RH), non-condensing
Storage altitude
- 10,000 ft (3,000 m) maximum
Electromagnetic Emissions and Immunity
Certifications
- CE mark, commercial
- FCC Part 15 class B
- CE/EN55032/24
- VCCI
- ACMA
- CSA safety
- KC
- BSMI
Package
Package Contents
- 1 x NETGEAR GS308EP
- 1 x Power adapter
- 1 x Wall installation kit
- 1 x Set of rubber feet
- 1 x Installation guide
