Synology RXD1215sas 12-Bay NAS Expansion Module Enclosure
Synology RXD1215sas NAS Storage Expansion
Please Note:Â This product is not a NAS, it is an expansion enclosure for an existing NAS device.
Synology RXD1215sas NAS Storage Expansion device is a unit specifically designed to work with Synology’s RC18015xs+ RackStation. When connected with the Synology RC18015xs+ RackStation, it delivers the massive scalability and uncompromising resiliency that 24/7 businesses require.
NAS Storage Expansion RXD1215sas
Key Features
- Un-populated twelve (12) bay storage expansion unit.
- Delivers massive scalability and uncompromising resiliency.
- Accommodate huge scalability up to 180 drives and max. raw storage beyond 1PB.
- Equipped with power supply units, SAS modules and system cooling fans.
Accomodate up to 180 drives
Up to fifteen Synology RXD1215sas expansion units can be connected to the dual RC18015xs+ computing nodes, accommodating massive scalability up to 180 drives and maximum raw storage beyond 1PB2. The shared storage architecture eliminates the need for data replication over the network, in addition to drastically reducing deployment costs.
Hardware redundancy enhances system uptime
The Synology RXD1215sas expansion unit is equipped with redundant hardware components, such as power supply units, SAS modules, and system cooling fans. In the event of component failure, the system continues operating normally while replacement parts are obtained and installed.
Specifications
Hardware specifications
Storage
- Drive Bay(s)
- 12
- Compatible Drive Type
- 3.5″ SAS HDD
- 2.5″ SAS HDD
- 2.5″ SAS SSD
- Maximum Internal Raw Capacity 96 TB (8 TB HDD X 12) (Capacity may vary by RAID types)
- Hot Swappable Drive
- RAID Management through Synology DSM
External Ports
- MiniSAS IN-port
- 2
- MiniSAS OUT-port
- 2
Appearance
- Size
- 88 mm X 430 mm X 692 mm
- Weight
- 18 kg
Power
- Power Recovery
- Synchronized with the Synology RackStation
- Power Supply Unit / Adapter
- 2 X 500W
- AC Input Power Voltage
- 100V to 240V AC
- Power Frequency
- 50/60 Hz, Single Phase
- Power Consumption*
- 248 W (Access)
- British Thermal Unit
- 846.21 BTU/hr (Access)
- Redundant Power Supply
Temperature
- Operating Temperature
-  5°C to 35°C (40°F to 95°F)
- Storage Temperature
- -20°C to 60°C (-5°F to 140°F)
- Relative Humidity
- 5% to 95% RH
Other specifications
- System Fan
- 60 mm X 60 mm X 4 pcs
- Easy Replacement System Fan
- Noise Level*
- 48 dB(A)
- Certification
- FCC Class A
- CE Class A
- BSMI Class A
- Warranty
- 5 Years
Environment and Packaging
- Environment
- RoHS Compliant
- Packaging Content
- Main Unit X 1
- Accessory Pack X 1
- AC Power Cord X 2
- Expansion Cable: MiniSAS X 2
- Quick Installation Guide X 1
Standard warranty: 5-years
