Meraki MR56 Cloud Managed WiFi 6 PoE+ Access Point w/ 3-Year Enterprise Licence (5951Mbps AX)

Meraki MR56-HW-3YR Cloud Managed PoE+WiFi 6 Access Point (AX)

The Meraki MR56 Cloud Managed WiFi 6 PoE+ Access Point raises the bar for wireless performance and efficiency. Designed for next-generation deployments in offices, schools, hospitals, shops, and hotels, the MR56 offers high throughput, enterprise-grade security, and simple management. The MR56 provides a maximum of 5.9 Gbps aggregate frame rate with concurrent 2.4 GHz and 5 GHz radios. A dedicated third radio provides real-time WIDS/WIPS with automated RF optimisation, and a fourth integrated radio delivers Bluetooth scanning and beaconing.

Key Features

• Includes a three (3) year Meraki licence for operational functionality.
• 8×8:8 MU-MIMO 802.11ax (WiFi 6).
• 5.9 Gbps dual-radio aggregate frame rate.
• 24×7 real-time WIDS/WIPS and spectrum analytics via dedicated third radio.
• Integrated Bluetooth Low Energy Beacon.
• Integrated scanning radio.
• Enhanced transmit power and receive sensitivity.
• Integrated enterprise security and guest access.
• Application-aware traffic shaping.
• Optimised for voice and video.
• Self-configuring, plug-and-play deployment.
• Sleek design blends into office environments.
• Full-time WiFi location tracking via dedicated 3rd radio.

Includes 3-Years Meraki Enterprise Edition Licence

This Enterprise Edition licence is for one (1) MR series access point, and features all of the following:

• Cloud-based centralised management, eliminates on-site hardware controller
• Network-wide visibility and control
• Massively scalable. (e.g. up to 10,000 access points)
• Out-of-band control plane: network traffic does not pass through the cloud, so the network stays up if connection to the cloud is lost
• Powerful multi-site management tools
• Automatic RF optimisation, network monitoring and alerts
• Seamless firmware and security updates
• Intuitive browser-based dashboard eliminates training and dedicated staff

Meraki Cloud Management

Management of the MR56 is performed through the Meraki cloud, with an intuitive browser-based interface that enables rapid deployment without time-consuming training or costly certifications. Because the MR56 is self-configuring and managed over the web, it can be deployed at a remote location in a matter of minutes, even without on-site IT staff.

24×7 monitoring via the Meraki cloud delivers real-time alerts if a network encounters problems. Remote diagnostic tools enable immediate troubleshooting over the web so that distributed networks can be managed with a minimum of hassle.

The MR56’s firmware is automatically kept up to date via the cloud. New features, bug fixes, and enhancements are delivered seamlessly over the web. This means no manual software updates to download or missing security patches to worry about.

Dual–radio aggregate frame rate of up to 5.9 Gbps

The 5 GHz 8×8:8 radio and 2.4 GHz 4×4:4 radio offer a combined dual–radio aggregate frame rate of 5.9 Gbps, with up to 4,804 Mbps in the 5 GHz band and 1,147 Mbps in the 2.4 GHz band. Technologies like transmit beamforming and enhanced receive sensitivity allow the MR56 to support a higher client density than typical enterprise-class access points, resulting in better performance for more clients, from each AP.

Multi User Multiple Input Multiple Output (MU-MIMO)

With support for features of 802.11ax (WiFi 6), the MR56 offers MU-MIMO and OFDMA for more efficient transmission to multiple clients. Especially suited to environments with numerous mobile devices, MU-MIMO enables multiple clients to receive data simultaneously. This increases the total network performance and improves the end user experience.

Dedicated third radio delivers 24×7 wireless security and RF analytics

The MR56’s dedicated dual-band scanning and security radio continually assesses the environment, characterising RF interference and containing wireless threats like rogue access points. There’s no need to choose between wireless security, advanced RF analysis, and serving client data – a dedicated third radio means that all functions occur in real-time, without any impact to client traffic or AP throughput.

Bluetooth Low Energy Beacon and scanning radio

An integrated fourth Bluetooth radio provides seamless deployment of BLE Beacon functionality and effortless visibility of Bluetooth devices. The MR56 enables the next generation of location-aware applications while future proofing deployments, ensuring it’s ready for any new customer engagement strategies.

Automatic cloud-based RF optimisation

The MR56’s sophisticated and automated RF optimisation means that there is no need for the dedicated hardware and RF expertise typically required to tune a wireless network. The RF data collected by the dedicated third radio is continuously fed back to the Meraki cloud. This data is then used to automatically tune the channel selection, transmit power, and client connection settings for optimal performance under even the most challenging RF conditions.

Integrated enterprise security and guest access

The MR56 features integrated, easy-to-use security technologies to provide secure connectivity for employees and guests alike. Advanced security features such as AES hardware-based encryption and Enterprise authentication with 802.1X and Active Directory integration provide wired-like security while still being easy to configure. One-click guest isolation provides secure, internet-only access for visitors. PCI compliance reports check network settings against PCI requirements to simplify secure retail deployments.

Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration

Meraki Systems Manager natively integrates with the MR56 to offer automatic, context-aware security. Systems Manager’s self-service enrolment helps to rapidly deploy MDM without installing additional equipment, and then dynamically tie firewall and traffic shaping policies to client posture.

Application-aware traffic shaping

The MR56 includes an integrated layer 7 packet inspection, classification, and control engine, enabling the configuration of QoS policies based on traffic type, helping to prioritise mission-critical applications while setting limits on recreational traffic like peer-to-peer and video streaming. Policies can be implemented per network, per SSID, per user group, or per individual user for maximum flexibility and control.

Voice and video optimisations

Industry standard QoS features are built-in and easy to configure. Wireless MultiMedia (WMM) access categories, 802.1p, and DSCP standards support all ensure important applications get prioritised correctly, not only on the MR56, but on other devices in the network. Unscheduled Automatic Power Save Delivery (U-APSD) and Target Wait Time features in 802.11ax (WiFi 6) clients ensure minimal battery drain on wireless VoIP phones.

Self-configuring, self-maintaining, always up-to-date

When plugged in, the MR56 automatically connects to the Meraki cloud, downloads its configuration, and joins the appropriate network. If new firmware is required, this is retrieved by the AP and updated automatically. This ensures the network is kept up-to-date with bug fixes, security updates, and new features.

Advanced analytics

Drilling down into the details of network usage provides highly granular traffic analytics. Visibility into the physical world can be enhanced with journey tracking through location analytics. Visitor numbers, dwell time, repeat visit rates, and track trends can all be easily monitored in the dashboard and deeper analysis is enabled with raw data available via simple APIs.

Specifications

Standard Warranty: Limited Lifetime
