Camera

Image Sensor

• 1/3″ Progressive Scan CMOS

Min. Illumination

• Colour: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR

Shutter Speed

• 1/3 s to 1/100,000 s

Day & Night

• IR cut filter

Angle Adjustment

• Pan: 0º to 355º
• Tilt: 0º to 75º
• Rotate: 0º to 355º

Slow Shutter

• Yes

Wide Dynamic Range

• 120 dB

Lens

Lens Size

• 2.8mm

Field of View

• Horizontal: 103º
• Vertical: 55º
• Diagonal: 123º

Aperture

• F1.4

Lens Mount

• M12

Aperture Type

• Fixed

DORI

DORI

• D: 60.0 m
• O: 23.8 m
• R: 12.0 m
• I: 6.0 m

Illuminator

IR Range

• Up to 30 m

Wavelength

• 850 nm

Smart Supplement Light

• Yes

Supplement Light

• IR

Video

Max. Resolution

• 2688 × 1520

Main Stream

• 50Hz:
  • 25fps (2688 x 1520, 1920 x 1080, 1280 x 720)
• 60Hz:
  • 30fps (2688 x 1520, 1920 x 1080, 1280 x 720)

Sub Stream

• 50Hz: 25fps (640 x 480, 640 x 360)
• 60Hz: 30fps (640 x 480, 640 x 360)

Third Stream

• 50Hz: 10fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• 60Hz: 10fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• Third stream is supported under certain settings.

Video Compression

• Main stream: H.265/H.264/H.265+/H.264+
• Sub-stream: H.265/H.264/MJPEG
• Third stream: H.265/H.264
• Third stream is supported under certain settings.

Video Bit Rate

• 32 Kbps to 8 Mbps

H.264 Type

• Baseline Profile/Main Profile/High Profile

H.265 Type

• Main Profile

H.264+

• Main Stream supports

H.265+

• Main Stream supports

Bit Rate Control

• CBR/VBR

Scalable Video Coding (SVC)

• H.264 and H.265 encoding

Region of Interest (ROI)

• 1 fixed region for each stream

Audio

Environment Noise Filtering

• Yes

Audio Sampling Rate

• 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Audio Compression

• G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC

Audio Bit Rate

• 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8-320Kbps(MP3)

Network

Simultaneous Live View

• Up to 6 channels

API

• ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK

Protocols

• TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets

User/Host

• Up to 32 users. 3 user levels: administrator, operator and user

Security

• Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface

Network Storage

• MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
• Together with high-end Hikvision memory card, memory card encryption and health detection are supported

Client

• iVMS-4200, Hik-Connect, Hik-Central

Web Browser

• Plug-in required live view: IE10+
• Plug-in free live view: Chrome 57.0+, Firefox 52.0+
• Local service: Chrome 57.0+, Firefox 52.0+


SNR

• > 52 dB

Day/Night Switch

• Day, Night, Auto, Schedule

Image Enhancement

• BLC (Back Light Compensation), HLC (High Light Compensation), 3D DNR (Digital Noise Reduction)

Image Parameters Switch

• Yes

Image Settings

• Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Interface

Alarm

• 1 input, 1 output (max. 12 VDC @30 mA)

Built-in Microphone

• Yes

Audio

• 1 x Input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 K ohms, interface type: non-equilibrium
• 1 x Output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 ohms, interface type: non-equilibrium

On-board Storage

• Built-in micro SD slot, support microSD/SDHC/SDXC card, up to 256 GB

Hardware Reset

• Yes

Communication Interface

• 1 x RJ45 10M/100M self-adaptive Ethernet port

Event

Basic Event

• Motion detection (human and vehicle targets classification), video tampering alarm, exception

Smart Event

• Scene change detection

Deep Learning Function

Face Capture

• Yes

Premier Protection

• Line crossing detection, intrusion detection, region entrance detection, region exiting detection

General

Startup and Operating Temperture

• -30ºC to 60ºC (-22ºF to 140ºF)

Startup and Operating Humidity

• Humidity 95% or less (non-condensing)

Storage Temperature

• -30ºC to 60ºC (-22ºF to 140ºF)

Storage Humidity

• 95% or less (non-condensing)

Power Supply

• 12 VDC ± 25%, reverse polarity protection
• PoE: 802.3af, class 3

Power Consumption and Current

• 12 VDC, 0.4 A, max. 5 W
• PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W

Power Interface

• Ø 5.5 mm coaxial power plug

Material

• Metal upper cover and base

Dimension

• Ø 121.4 x 92.2 mm (4.8 x 3.6 in.)

Weight (approx.)

• 580g (1.3 lb.)

Linkage Method

• Upload to NAS/memory card, notify surveillance centre, trigger record, trigger capture, audible warning

Web Client Language

• 33 languages
  • Bulgarian
  • Chinese (Traditional)
  • Croatian
  • Czech
  • Danish
  • Dutch
  • English
  • Estonian
  • Finnish
  • French
  • German
  • Greek
  • Hungarian
  • Italian
  • Japanese
  • Korean
  • Latvian
  • Lithuanian
  • Norwegian
  • Polish
  • Portuguese (Brazil)
  • Portuguese (Europe)
  • Romanian
  • Russian
  • Serbian
  • Slovak
  • Slovenian
  • Spanish
  • Swedish
  • Thai
  • Turkish
  • Ukrainian
  • Vietnamese

General Function

• Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter

Software Reset

• Yes

Firmware Version

• V5.5.112

Approval

EMC

• FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015)

Safety

• UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); LOA (IEC/EN 60950-1)

Environment

• CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Protection

• Ingression protection: IP67 (IEC 60529-2013)
• Impact protection: IK10 (IEC 62262:2002)
