Dimensions

• 76.5 x 76.5 x 26.4 mm (3.01 x 3.01 x 1.04″)

Weight

• 77 g (2.72 oz)

Networking Interface Speeds

• (1) GPON WAN, ITU G.984,
• 2.488 Gbps Downstream,
• 1.244 Gbps Upstream
• (1) GbE LAN, 10/100/1000 Mbps

Management Interface

• In-Band Ethernet/PON

Normal Optical Power Range

• TX (Class B+): 1.5 dBm to 5 dBm
• RX: -28 dBm to -8 dBm

Power Method

• Micro-USB: 5V, 1A
• 24V Passive PoE (Pins +4, 5; -7, 8)

Power Supply

• Micro-USB Power Adapter*: 5V, 1A
• Max. Power Consumption 3.5W

Supported Voltage Range

• 4.7 to 5.3V

Processor Specs

• MIPS32, 240 MHz

Memory Information

• 128 MB DDR3

Buttons

• (1) Reset

Operating Temperature

• -10 to 45° C (14 to 113° F)

Operating Humidity

• 10 to 90% Noncondensing

Certifications

• CE, FCC, IC

* Included only in the single-pack of the UF-LOCO

Status LEDs
The easy-to-read LEDs provide status information: Ethernet connection, signal strength, and power.

Versatile Power
The UFiber Loco can be powered by either 24V passive PoE or by micro-USB, offering maximum flexibility.

Designed for Integration
Up to 128 UFiber loco (UF-Loco) devices can be connected to a single GPON port. Supporting GPON links of up to 20 km, the UFiber loco integrates with the UFiber OLT and third-party OLT devices.

The UFiber network is intelligently managed using the included UNMS™ (Ubiquiti® Network Management System) controller. UFiber devices consist of the UFiber OLT (deployed at the provider premises) and the UFiber Nano G or loco clients, which function as ONU CPEs (Customer Premises Equipment).
