Ubiquiti LTU-LR Outdoor 5GHz PtMP Antenna WiFi Point to Point Link 26 dBi is a 5GHz subscriber station, designed for long-range applications.

It functions as a CPE (Customer Premises Equipment) in a Point-to-Multi Point (PtMP) environment with the LTU Rocket (sold separately) as the base station.

The LTU LR incorporates an innovative industrial design with advanced technology. It features LTU technology that breaks through the limitations of 802.11 WiFi technology and supports 1024 QAM for high performance and flexible bandwidth (10/20/30/40/50 MHz).

Key Features

• Proprietary LTU technology.
• CPE modes.
• 10/20/30/40/50 MHz channel bandwidth.
• Central configuration management from AP side.
• Frequency split.
• Improved noise immunity.
• Innovative design.
• Quick mounting and alignment.
• Range up to 30 km.
• Functions in a PtMP environment with the LTU-Rocket (sold separately) as the base station.

Proprietary LTU Technology

Based on Ubiquiti’s LTU technology, the LTU LR is not impeded by the limitations of standard 802.11 WiFi technology.

Its custom LTU silicon and radio architecture provide up to 600+ Mbps of real TCP/IP throughput and modulation rates of up to 4096 QAM.

CPE Modes

The LTU LR supports both bridged and built-in hardware NAT router modes to suit your specific deployment.

Frequency Split

The LTU LR can use different frequencies for TX and RX to avoid interference.

Improved Noise Immunity

The LTU LR directs RF energy in a tighter beam width. With the focus in one direction, the LTU LR blocks or spatially filters out noise to improve noise immunity.

This is especially important in an area crowded with other RF signals of the same or similar frequency.

Innovative Design

Ubiquiti’s Inner Feed technology integrates the radio into the feed horn of a 26 dBi antenna, so there is no need for a cable. This improves performance because it eliminates cable losses.

Quick Mounting and Alignment

The LTU LR features a large reflector size and easy elevation adjustment (azimuth is adjusted by rotation around the pole).

Channel Width Flexibility

Channel width flexibility allows independent TX and RX channel frequency configurations anywhere within the radio band to avoid local interference. Channel width options include the following:

• 10 MHz
• 20 MHz
• 30 MHz
• 40 MHz
• 50 MHz
• Up to 100 MHz

Auto Power Adjustments

By default, the Auto Output Power option allows the LTU LR to set the output power (EIRP) to the appropriate level.

Signal Control

The LTU LR’s TX output power is controlled by the AP’s target TX output power. A PtMP network can manage signal levels to enhance network stability and achieve optimal wireless performance with the highest possible modulation.

Convenient Configuration

To manage the LTU LR, you have two options: the LTU Configuration Interface or the Ubiquiti Network Management System (UNMS).

Either option lets you manually configure the LTU LR. Within the LTU Configuration Interface, you can manually configure the LTU LR or manage it from the AP side using the Find My AP feature.

The LTU LR will automatically scan for APs using the same channel bandwidth. Select the appropriate AP and then use it to configure the LTU LR.

LTU Configuration Interface

PtMP Dashboard

The Dashboard offers map view so you can visualize the network. The map view shows your PtMP links overlaid on a geographic map.

New graphs provide instant status updates and help you to detect connectivity issues and their effects on PtMP performance:

• The airtime distribution bar graph displays in real time how much airtime each CPE is using. Click any point to view the airtime and link score for a specific CPE.
• The AP RF environment bar graph shows ambient RF noise levels across the frequency spectrum.
• The combined remote RF environment bar graph also shows ambient RF noise levels but for the combined environment of all of the remote CPEs.
• The local and remote RX rate histograms show the receive modulation rates of the various CPEs.

Real-Time Spectral Analysis

airView spectral analysis runs on a dedicated and independent receiver, which has excellent EVM (Error Vector Magnitude) performance.

The receiver can also perform other tasks, such as a search for channel occupancy, DFS detection, and automatic channel/frequency assignment.

Calibration (signal level measurement accuracy) and resolution bandwidth options are enhanced. Spectral zoom (user-defined scan limits) is also available.

UNMS Network Controller

• Manage your networks from a single control plane.
• Intuitive and robust configuration, control and monitoring.
• Remote firmware upgrade.
• Automatic client shaping.
• Customer billing.

Specifications

Standard Warranty: 1-Year
