TP-Link TL-SG2428P JetStream Managed PoE+ 24 Port Gigabit Switch
£346.39 inc.VAT / £288.66 exc.VAT
TP-Link TL-SG2428P JetStream 24-Port Smart Managed Rackmount Gigabit PoE+ Switch w/ 4 x 1Gbps SFP Ports (250 W)
TP-Link TL-SG2428P JetStream 24-Port Smart Managed Rackmount Gigabit PoE+ Switch is a cost-effective product solution for small and medium businesses.Â
Out of stock
TP-Link TL-SG2428P JetStream 24-Port Smart Managed Rackmount Gigabit PoE+ Switch w/ 4 x 1Gbps SFP Ports (250 W)
TP-Link TL-SG2428P JetStream Managed PoE+ 24 Port Gigabit Switch
TP-Link TL-SG2428P JetStream Managed PoE+ 24 Port Gigabit Switch is a cost-effective product solution for small and medium businesses.
Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster.
Furthermothe easy-to-use web management interface, along with SNMP and RMON, means faster setup and configuration with less downtime.
Key Features
- Twenty-four (24) 10/100/1000 Mbps RJ45 ports.
- Four (4) Gigabit SFP slots.
- 250 W PoE Budget: 24 x 802.3at/af-compliant PoE+ ports with a total power supply of 250 W.
- Full Gigabit Ports: 24 x Gigabit PoE+ ports and 4 x Gigabit SFP Slots provide high-speed connections.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Static Routing: Helps route internal traffic for more efficient use of network resources.
- Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
- Optimize Voice and Video Applications: L2/L3/L4 QoS and  snooping.
- IPv6: IPv6 support with dual IPv4/IPv6 stack, MLD snooping, IPv6 neighbor discovery.
Software Defined Networking (SDN) with Cloud Access
Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralised cloud management. Omada creates a highly scalable network — all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
Specifications
Standards and Protocols
- IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Interface
- 24 × 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
- 4 × Gigabit SFP Slots
Network Media
- 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
- 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
- 1000BASE-X: MMF, SMF
Fan Quantity
- 2
PoE+ Ports(RJ45)
- Standard: 802.3at/af compliant
- PoE+ Ports: 24 Ports
- Power Supply: 250 W
Dimensions ( W x D x H )
- 17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm)
Mounting
- Rack Mountable
Max Power Consumption
- 32.1 W (110 V/ 60 Hz with no PD connected)
- 308.6 W (110 V/ 60 Hz with 250 W PD connected)
Max Heat Dissipation
- 109.53 BTU/h (with no PD connected)
- 1052.94 BTU/h (with 250 W PD connected)
PERFORMANCE
Bandwidth/Back plane
- 56 Gbps
Packet Forwarding Rate
- 41.7 Mpps
MAC Address Table
- 8K
Packet Buffer Memory
- 4.1 Mbit
Jumbo Frame
- 9KB
SOFTWARE FEATURES
Quality of Service
- Support 802.1p CoS/DSCP priority
- Support 8 priority queues
- Queue scheduling: SP, WRR, SP+WRR
- Port/Flow- based Rate Limiting
- IPv6 QoS
- Voice VLAN
L2 and L2+ Features
- Static Routing
- DHCP Relay
- DHCP Server
- IGMP Snooping V1/V2/V3
- 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group)
- Spanning Tree STP/RSTP/MSTP
- BPDU Filtering/Guard
- TC/Root Protect
- Loopback detection
- 802.3x Flow Control
- LLDP, LLDP-MED
VLAN
- Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs)
- MAC/Protocol-based VLAN
Access Control List
- L2–L4 package filtering
- MAC ACL
- IP ACL
- Combined ACL
- IPv6 ACL
Security
- AAA
- Port Security
- DHCP Snooping
- IP-MAC-Port Binding
- IPv6-MAC-Port Binding
- ARP Inspection
- 802.1x and Radius Authentication
- SSH v1/v2
- SSL v3/TLSv1.2
- Broadcast/Multicast/Unknown-unicast Storm Control
- Dos Defend
IPv6
- Dual IPv4/IPv6 stack
- Multicast Listener Discovery (MLD) Snooping
- IPv6 neighbour discovery (ND)
- Path maximum transmission unit (MTU) discovery
- Internet Control Message Protocol (ICMP) version 6
- TCPv6/UDPv6
IPv6 Applications
- DHCPv6 Client
- Ping6
- Tracert6
- Telnet (v6)
- IPv6 SNMP
- IPv6 SSH
- IPv6 SSL
- Http/Https
- IPv6 TFTP
MANAGEMENT
Omada App
- Yes
Centralized Management
- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
Cloud Access
- Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Management Features
- Web-based GUI and CLI management
- SNMP v1/v2c/v3,compatible with public MIBs and TP-Link private MIBs
- RMON (1, 2, 3, 9 groups)
- CPU Monitoring
- Port Mirroring
- Firmware Upgrade: TFTP & Web
- System Diagnose: VCT
- SYSLOG & Public MIBS
- Dual Image
- EEE
OTHERS
Certification
- CE, FCC, RoHS
System Requirements
- Microsoft Windows XP, Vista or Windows 7, Windows 8, Windows 10, MAC OS, NetWare, UNIX or Linux.
Environment
- Operating Temperature: 0–50 ºC (32–122 ºF);
- Storage Temperature: -40–70 ºC (-40–158 ºF)
- Operating Humidity: 10–90% RH non-condensing
- Storage Humidity: 5–90% RH non-condensing
Package Contents
- 1 x TL-SG2428P
- 1 x Power Cord
- 1 x Installation Guide
- 1 x Rackmount Kit
- 1 x Rubber Feet
Standard Warranty: Limited Lifetime
