Ruckus AT-2401-DP dual polarized Antenna 5GHz

Ruckus AT-2401-DP Antenna

Ruckus AT-2401-DP Antenna is a 5GHz dual polarized high gain 24dBi directional Antenna.

Specification

Product Classification
Regional Availability: Asia | Australia/New Zealand | EMEA | Latin America | North America
Product Type : Antenna
Product Brand : RUCKUS®

General Specifications
Application : Long range backhaul /PtP/PtMP Non-Root
Antenna Gain : 24.5 dBi/23.5 dBi
Polarization : Vertical & Horizontal
Bandwidth H/V @ 3 dB :7-9/7-9 degrees
Connector Location : Two N-type, two 1 m RF cables included
IP Rating : IP-67
Mounting : Wall/Pole Mount, mounting kit included
Wi-Fi Band : 5 GHz

Dimensions
System Dimensions : 370 mm × 370 mm × 40 mm

Environmental Specifications
Operating Temperature :-40 °C to +65 °C (-40 °F to +149 °F)

Packaging and Weights
Weight, net : 1800 g | 3.968 lb
