Hikvision DS-2CD2T86G2-2I-2.8MM AcuSense Bullet Security IP Camera
Hikvision DS-2CD2T86G2-2I AcuSense, Pro EasyIP 4.0 Outdoor 4K UHD PoE Bullet IP Camera w/ 2.8mm Lens & 60m Night Vision (8 MP)
The Hikvision DS-2CD2T86G2-2I AcuSense, Pro EasyIP 4.0 Black Outdoor 4K UHD PoE Bullet IP Camera is a high performance outdoor surveillance camera capable of transmitting H.265 video at up to 3840 x 2160 resolution. Featuring a 2.8mm lens, day and night functionality with IR cut filter, Wide Dynamic Range (WDR) and Digital Noise Reduction (DNR), this Hikvision DS-2CD2T86G2-2I AcuSense, Pro EasyIP 4.0 Outdoor 4K UHD PoE Bullet IP Camera is equipped to tackle any outdoor security solution. Furthermore, this camera features an alarm trigger for motion detection and tampering.
Hikvision DS-2CD2T86G2-2I AcuSense, Pro EasyIP 4.0 Outdoor 4K UHD PoE Bullet IP Camera w/ 2.8mm Lens & 60m Night Vision (8 MP)
Hikvision DS-2CD2T86G2-2I-2.8MM AcuSense Bullet Security IP Camera
The Hikvision DS-2CD2T86G2-2I-2.8MM AcuSense Bullet Security IP Camera is a high performance outdoor surveillance camera capable of transmitting H.265 video at up to 3840 x 2160 resolution. Featuring a 2.8mm lens, day and night functionality with IR cut filter, Wide Dynamic Range (WDR) and Digital Noise Reduction (DNR), this Hikvision DS-2CD2T86G2-2I AcuSense, Pro EasyIP 4.0 Outdoor 4K UHD PoE Bullet IP Camera is equipped to tackle any outdoor security solution. Furthermore, this camera features an alarm trigger for motion detection and tampering.
Key Features
- 1/1.8″ Progressive Scan CMOS.
- 3840 × 2160 @ 20fps.
- 2.8 mm fixed lens.
- 120dB WDR (Wide Dynamic Range).
- Powered by DarkFighter.
- H.265+, H.265, H.264+, H.264.
- Built-in micro SD/SDHC/SDXC card slot, up to 256 GB.
- IP67 protection rating.
- Human and vehicle classification alarm based on deep learning.
AcuSense
Empowered by deep learning algorithms, Hikvision AcuSense technology brings human or vehicle target classification alarms to front- and back-end devices. The system can greatly reduce false alarms generated by targets other than humans or vehicles, vastly improving alarm efficiency and effectiveness.
Specifications
Camera
Image Sensor
- 1/1.8″ Progressive Scan CMOS
Min. Illumination
- Colour: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed
- 1/3 s to 1/100,000 s
Slow Shutter
- Yes
Day & Night
- IR Cut Filter
WDR (Wide Dynamic Range)
- 120 dB
Angle Adjustment
- Pan: 0º to 360º
- Tilt: 0º to 90º
- Rotate: 0º to 360º
Lens
Lens Type
- Fixed lens, 2.8 mm
Aperture
- F1.6
Field of View
- Horizontal: 110.7º
- Vertical: 59.1º
- Diagonal: 131º
Lens Mount
- M16
Illuminator
IR Range
- Up to 60 m
Wavelength
- 850 nm
Video
Max. Resolution
- 3840 x 2160
- Note: When the main stream resolution is 3840 × 2160, max frame rate is 20 fps for all streams.
Main Stream
- 50Hz: 20fps (3840 x 2160, 3072 x 1728), 25fps (2688 x 1520, 1920 x 1080, 1280 x 720)
- 60Hz: 20fps (3840 x 2160, 3072 x 1728), 30fps (2688 x 1520, 1920 x 1080, 1280 x 720)
Sub-Stream
- 50Hz: 25fps (640 x 480, 640 x 360, 320 x 240)
- 60Hz: 30fps (640 x 480, 640 x 360, 320 x 240)
Third Stream
- 50Hz: 25fps (1280 x 720, 640 x 480, 640 x 360, 320 x 240)
- 60Hz: 30fps (1280 x 720, 640 x 480, 640 x 360, 320 x 240)
Video Compression
- Main stream: H.265+/H.264+/H.265/H.264
- Sub-stream: H.265/H.264/MJPEG
- Third stream: H.265/H.264
H.264 Type
- Baseline Profile/Main Profile/High Profile
H.265 Type
- Main Profile
Video Bit Rate
- 32 Kbps to 16 Mbps
Scalable Video Coding (SVC)
- H.264 and H.265 encoding support
Smart Feature-Set
Perimeter Protection
- Line crossing detection, intrusion detection, region entrance detection, region exiting detection (Human & Vehicle classification)
Face Capture
- Yes
Basic Event
- Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection
Linkage Method
- Upload to FTP/NAS/memory card, notify surveillance centre, send email, trigger recording, trigger capture
Region of Interest
- 1 fixed region for main stream, sub-stream and third stream
Image Enhancement
- BLC (Back Light Compensation), HLC (High Light Compensation), 3D DNR (Digital Noise Reduction)
Image Setting
- Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser
Day/Night Switch
- Day/Night/Auto/Schedule
Network
Network Storage
- microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
Protocols
- TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
API
- ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Security
- Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Simultaneous Live View
- Up to 6 channels
User/Host
- Up to 32 users, 3 levels: administrator, operator and user
Client
- iVMS-4200, Hik-Connect, Hik-Central
Web Browser
- Plug-in required live view: IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11
- Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Interface
Communication Interface
- 1 x RJ45 10M/100M self-adaptive Ethernet port
On-board storage
- Built-in micro SD/SDHC/SDXC slot, up to 256 GB
General
Web Client Language
- 32 languages
- Bulgarian
- Chinese (Traditional)
- Croatian
- Czech
- Danish
- Dutch
- English
- Estonian
- Finnish
- French
- German
- Greek
- Hungarian
- Italian
- Japanese
- Korean
- Latvian
- Lithuanian
- Norwegian
- Polish
- Portuguese (Brazil)
- Portuguese (Europe)
- Romanian
- Russian
- Serbian
- Slovak
- Slovenian
- Spanish
- Swedish
- Thai
- Turkish
- Vietnamese
General Function
- Anti-flicker, three streams, heartbeat, mirror, privacy masks, pixel counter
Reset
- Reset via reset button on camera body, web browser and client software
Startup and Operating Temperature
- -30ºC to 60ºC (-22ºF to 140ºF)
Startup and Operating Humidity
- 95% or less (non-condensing)
Storage Temperature
- -30ºC to 60ºC (-22ºF to 140ºF)
Storage Humidity
- 95% or less (non-condensing)
Power Supply
- 12 VDC ± 25%, Ø 5.5 mm coaxial power plug; reverse polarity protection; PoE (802.3af, class 3)
Power Consumption and Current
- 12 VDC, 0.63 A, max. 7.5 W; PoE (802.3af, 36 V to 57 V), 0.25 A to 0.16 A, max. 9 W
Material
- Metal
Dimensions
- Ø105 x 290 mm (Ø 4.1 x 11.4 in.)
Weight
- Approx. 1270 g (2.8 lb.)
Approval
EMC
- FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety
- UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Chemistry
- CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection
- Ingress protection: IP67 (IEC 60529-2013)
4K AcuSense Fixed Bullet Network Camera
- High quality imaging with 8 MP resolution
- Excellent low-light performance with powered-by-DarkFighter technology
- Efficient H.265+ compression technology
- Clear imaging against strong back light by 120 dB true WDR technology
- Focus on human and vehicle targets classification based on deep learning
- Water and dust resistant (IP67)
Standard Warranty: 3-Years
Warranty is invalidated by the incorrect installation of the product. In particular, failure to make correct use of the weather-proof gland will cause oxidation of the connector pins, resulting in irreparable damage to the camera.
