Camera

Image Sensor

• 1/2.5″ Progressive Scan CMOS

Min. Illumination

• Colour: 0.008 lux @(F1.2, AGC ON), 0.014 lux @(F1.6, AGC ON), 0 lux with IR

Shutter Speed

• 1/3 s to 1/100,000 s

Slow Shutter

• Yes

Auto-Iris

• No

Day & Night

• IR Cut Filter

Digital Noise Reduction

• 3D DNR

WDR

• 120dB

3-Axis Adjustment

• Pan: 0º to 360º
• Tilt: 0º to 75º
• Rotate: 0º to 360º

Lens

Focal Length

• 2.8 mm

Aperture

• F1.6

Focus

• Fixed

FOV

• Horizontal: 109º
• Vertical: 60º
• Diagonal: 131º

Lens Mount

• M12

IR

IR Range

• Up to 30 m

Wavelength

• 850nm

Compression Standard

Video Compression

• Main stream: H.265/H.264
• Sub-stream: H.265/H.264/MJPEG
• Third stream: H.265/H.264

H.264 Type

• Main Profile/High Profile

H.264+

• Main stream supports

H.265 Type

• Main Profile

H.265+

• Main stream supports

Video Bit Rate

• 32 Kbps to 16 Mbps

Smart Feature-set

Behaviour Analysis

• Line crossing detection
• Intrusion detection
• Object removal detection
• Unattended baggage detection

Exception Detection

• Scene change detection

Face Detection

• Yes

Region of Interest

• Support 1 fixed region for main stream and sub-stream


Max. Resolution

• 2688 x 1520

Main Stream

• 50Hz: 25 fps (2688 x 1520, 2304 x 1296, 1920 x 1080)
• 60Hz: 30 fps (2688 x 1520, 2304 x 1296, 1920 x 1080)

Sub-Stream

• 50Hz: 25 fps (640 x 480, 640 x 360, 320 x 240)
• 60Hz: 30 fps (640 x 480, 640 x 360, 320 x 240)

Third Stream

• 50Hz: 25 fps (1280 x 720, 640 x 360, 352 x 288)
• 60Hz: 30 fps (1280 x 720, 640 x 360, 352 x 240)

Image Enhancement

• BLC/3D DNR/HLC

Image Settings

• Rotate mode
• Saturation
• Brightness
• Contrast
• Sharpness
• White balance
• Adjustable by client software or web browser

Target Cropping

• No

SVC

• H.264 and H.265 encoding support

Day/Night Switch

• Day/Night/Auto/Schedule

Network

Network Storage

• Supports microSD/SDHC/SDXC card (128G)
• Local storage
• NAS (NFS, SMB/CIFS)
• ANR

Alarm Trigger

• Motion detection
• Video tampering
• Network disconnected
• IP address conflict
• Illegal login
• HDD full
• HDD error

Protocols

• TCP/IP
• ICMP
• HTTP
• HTTPS
• FTP
• DHCP
• DNS
• DDNS
• RTP
• RTSP
• RTCP
• PPPoE
• NTP
• UPnP
• SMTP
• SNMP
• IGMP
• 802.1X
• QoS
• IPv6
• Bonjour

General Function

• One-key reset
• Anti-flicker
• Three streams
• Heartbeat
• Mirror
• Password protection
• Privacy mask
• Watermark
• IP address filter

Firmware Version

• V5.5.80

API

• ONVIF (PROFILE S, PROFILE G)
• ISAPI

Simultaneous Live View

• Up to 6 channels

User/Host

• Up to 32 users
• 3 levels: Administrator, Operator and User

Client

• iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500

Web Browser

• Plug-in required live view:
  • IE8+
  • Chrome 41.0-44
  • Firefox 30.0-51
  • Safari 8.0-11
• Plug-in free live view:
  • Chrome 45.0+
  • Firefox 52.0+

Interface

• Communication Interface
• 1 x RJ45 10M/100M self-adaptive Ethernet port

On-board storage

• Built-in microSD/SDHC/SDXC slot, up to 128 GB

Reset Button

• Yes

General

Operating Conditions

• Temperature: -30 ºC to +60 ºC (-22 ºF to +140 ºF)
• Humidity: 95% or less (non-condensing)

Power Supply

• 12 VDC ± 25%, Ø 5.5 mm coaxial plug power
• PoE(802.3af, class 3)

Power Consumption and Current

• 12 VDC, 0.5 A, max. 6 W
• PoE (802.3af, 36 V to 57 V), 0.3 A to 0.2 A, max. 7.5 W

Protection Level

• IP67

Material

• Metal

Dimensions

• Ø 127.3 x 95.9 mm (Ø 5″ x 3. 8″)

Weight

• 620 g (1.4 lb.)
