Dahua VTO3211D-P2 Two Button ‘Villa Style’ Video Entrance Unit,2MP HD

Dahua VTO3211D-P2 Two Button ‘Villa Style’ Video Entrance Unit

Dahua VTO3211D-P2 Two Button ‘Villa Style’ Video Entrance Unit is a 2MP High Definition Day/Night Camera and Omni directional mic and built in speaker.

Calls indoor monitor and Mobile phone support with push notification, IP65 Weatherproof Design; IK08 Aluminium Construction.

Key Features

• 2MP High Definition Day/Night Camera
• 140º wide angle lens
• Omni directional mic and built in speaker
• Calls indoor monitor
• Mobile phone support with push notification
• Integrated Mifare Proximity Reader
• Hardwired Network Connection
• PoE or 12Vdc power input
• IP65 Weatherproof Design; IK08 Aluminium Construction
• Surface Mount Design

Specifications

System

• Main Processor : Embedded processor
• Operating System : Embedded Linux operating system
• Button Type : Mechanical
• Interoperability : ONVIF
• Network Protocol : SIP; P2P; IPv4; DNS; RTSP; RTP; TCP; UDP

Baisc

• Camera : 1/2.8″ 2MP CMOS high definition, low illumination/WDR/color/IR
• Angle of View : Horizontal: 129°; vertical: 74°; diagonal: 147°
• WDR : 120dB
• Noise Reduction : 3D noise reduction
• Video Compression: H.264
• Video Resolution : Main stream: WVGA, 720P, D1 | Sub stream: CIF, WVGA, QVGA, 1080P, D1

• Frame Rate : PAL: 25 fps | NTSC: 30 fps
• Video Bit Rate : 256K to 4M
• Light Compensation : Auto IR
• D/N :ICR auto switch
• Audio Compression : G.711Mu; G.711u; PCM
• Audio Input : 1
• Audio Output : Built-in speaker
• Audio Mode : Two-way audio
• Audio Enhancement :  Echo suppression and cancellation/digital noise reduction
• Audio Bit Rate : 16KHz, 16Bit

Function

• Communication : Full digital
• Unlock Mode : Card/App/indoor monitor unlock
• Card Type : IC card
• Motion Detection : Video Motion Detection
• Auto Snapshot : Auto snapshot can only be enabled on indoor monitors
• Leave Photos and Messages : Yes (Insert an SD card into the indoor monitor)
• Web Configuration : Yes

Performance

• Card Reading Distance : 3cm–5cm
• Casing :PC+Aluminum alloy, metal frame

Capacity

• Card Capacity : 10,000

Port

• RS-485 : 1
• Electric Lock : 1
• Alarm Input : 1
• Alarm Output : 1
• Exit Button : 1
• Door Status Detection : 1
• Lock Control : 1, normally closed by default
• Network : 1 10Mbps/100Mbps network port (8-core white ribbon cable)

Alarm

• Tamper Alarm : Yes

General

• Color : Greyish-black
• Power Supply : 12V DC 1A Standard PoE
• Installation : Surface mount
• Certifications : CE/FCC
• Accessory : Alarm ribbon cable
• Dimensions : 181 mm×101 mm×31 mm (7.13″ × 3.98″ × 1.22″)
• Protection Grade :IP65 (silicone sealant is needed, see the quick start guide) IK08
• Operating Temperature : –30°C to + 60°C (–22°F to +140°F)
• Operating Humidity : 10%RH–95%RH (non-condensing)
• Operating Environment : Outdoor
• Operating Altitude : Beneath 3000 m (9842.51 ft)
• Power Consumption :Standby ≤1W, working ≤7W
• Gross Weight : 660 g (5.51 lb)
