Function

High-quality image : Industry-specific CMOS image sensor with high sensitivity, high SNR and excellent WDR provides lifelike images 24/7.

Impressive performance : High-performance CPU processor helps extract and analyze information of motor and non-motor vehicles in real-time, providing vehicle feature details for business decision-making.

High-level protection :Integrated design with low power consumption, and IP67 protection grade, suitable for various harsh environments.

Easy installation : Built-in LED illuminator and motorized vari-focal lens, providing ease of installation and commissioning.

Specification

Basic

• Illuminator Number : 6 IR illuminators, brightness adjustable
• Image Sensor : 1/1.8” CMOS
• Image Resolution :2688 × 1520 (OSD black strip excluded)
• Video Resolution :

Main stream: 4M (2688 × 1520), 1080p (1920 × 1080), 720p (1280 × 720)
Sub stream: 720p (1280 × 720), D1 (704 × 576, 704 × 480), CIF (352 × 288, 352 × 240)

• Video Frame Rate :PAL: Main stream (2688 × 1520@25 fps, 1920 × 1080@25 fps, 1280 × 720@25 fps), sub stream: (1280 × 720@25 fps, 704 × 576@25fps, 352 × 288@25 fps)
  NTSC: Main stream (2688 × 1520@30 fps, 1920 × 1080, 1280 × 720@30 fps), sub stream (1280 × 720@30 fps, 704 × 408@30 fps, 352 × 240@30 fps)
• Bit Rate :   H.264B: 32 Kbps–32768 Kbps
  H.264M: 32 Kbps–32768 Kbps
  H.264H: 32 Kbps–32768 Kbps
  H.265: 32 Kbps–32768 Kbps
  MJPEG: 512 Kbps–65536 Kbps
• Video Compression : H.264B/H.264M/H.264H/H.265/MJPEG
• Picture Encoding Format : JPEG
• Noise Reduction : 3D NR
• White Balance : Full auto, auto color temperature range, customized color temperature
• Electronic Shutter Speed : 1/50–1/10,000 auto or manual
• WDR : 96 db
• Edge Enhancement : Yes
• Exposure Mode : Full auto, customized auto, customized
• Iris Control : Auto iris (W:1.4—T:2.15)

Performance

• Trigger Mode : Video detection; I/O coil
• Shutter : Single shutter
• Storage  : Built-in TF card slot. Supports Kingston 16 G, 32 G, 64 G, and 128 G; Dahua 16 G, 32 G, 64 G, and 128 G; SanDisk 16 G, 32 G, 64 G, and 128 G
• Image Tampering Prevention : Yes. Video/picture can be checked through watermark and verification
• Field of View : H: 114.6° (W)–48.3° (T) | V: 59.0° (W)–27.1° (T) | D: 141.6° (W)–55.5° (T)
• Illumination Distance : 12 m (39.37 ft)
• Capture Distance : 3 m–6 m (9.84 ft–19.69 ft)
• Detected Width : 3 m –4 m (9.84 ft–13.12 ft)
• Min. Illumination : 0.002 lx (built-in illuminator on)
• Max. Detection Speed :30 km/h (18.64 miles per hour)
• Alarm Event :Alarm for events of no storage card, storage card no space, storage card error, network disconnection, IP conflict, and illegal access
• Security :Authorized username and password, MAC address binding, HTTPS encryption, IEEE 802.1x, and network access control
• OSD Overlay : Supports overlay of time, address, plate, vehicle (color, type, accuracy), vehicle posture, counterfeit, checkpoint direction, trigger source, and custom
• Automatic Network Replenishment (ANR) Yes. Platform/FTP
• Auto Registration : Yes

Intelligence

• Vehicle Detection : Vehicle capture rate ≥ 99%
• Vehicle Recognition : Supports recognizing vehicle type, vehicle color, features of driver and front-seat passenger, licensed/unlicensed vehicle. Vehicle recognition rate ≥ 95%
• Video Metadata : Yes
• Intelligent Track Frame : Intelligent frame display. Supports displaying vehicle plate and vehicle path

Port

• Lens Mount : Φ16
• Analog Output : 1
• Network : 1 × 100/1000 M Ethernet port (RJ-45)
• RS-485 : 2
• RS-232  : 1
• Alarm Input : 3, optocoupler input (on-off input)
• Alarm Output : 3 ports. 2-channel optocoupler output, 1-channel relay output, which can connect to devices such as barriers
• Audio Input : 1-channel RCA port
• Audio Output : 1-channel RCA port

General

• Power Supply : 12V DC, 24V AC, PoE+
• Power Consumption : < 20 W
• Operating Temperature : −30°C to +65°C (−22°F to +149 °F)
• Operating Humidity : 10%RH–90%RH (no condensation)
• Casing : Metal + plastic
• Protection Grade : IP67
• Dimensions : 486.7 mm × 124.3 mm × 185.5 mm (19.16″ × 4.89″ × 7.30″) (L × W × H)
• Net Weight : 1.9 kg (4.19 lb)
• Gross Weight : 3.3 kg (7.28 lb)
• Installation : Bent pole bracket (included)
• Lens : Standard 2.7 mm–12 mm (0.11”–0.47”)

Certification

• CE, FCC : Yes
• RoHS : Yes
