Dahua IPC-HFW1530S-S6 5MP Entry IR Fixed-focal Bullet Network Camera

Dahua IPC-HFW1530S-S6 5MP Entry IR Fixed-focal Bullet Network Camera

Dahua IPC-HFW1530S-S6 5MP Entry IR Fixed-focal Bullet Network Camera with efficient H.265 / H.264 image compression algorithm for clear and smooth video streaming at maximal resolution of 5 Mpx.

The range of IR illumination according to the manufacturer data, depends on outer conditions (visibility – air transparency, environment, wall colors ie. scene reflectance).

PoE powering possibility, compatible with the 802.3af standard makes the device more universal and easier to install.

Key Features

• 5MP Entry IR Fixed Focal Bullet Network Camera
• H.265 & 264 dual-stream encoding
• Built-in IR LED; maximum 30m illumination
• 2.8mm Fixed Focal Lens
• IP67; PoE; 12Vdc

Specification

Camera

• Image Sensor : 1/2.7″ CMOS
• Max. Resolution : 2880 (H) × 1620 (V)
• ROM : 16 MB
• RAM : 128 MB
• Scanning System : Progressive
• Electronic Shutter Speed : Auto/Manual 1/3 s–1/100,000 s
• Min. Illumination : 0.03 Lux@F2.0 (Color, 30 IRE) | 0.003 Lux@F2.0 (B/W, 30 IRE) |0 Lux (Illuminator on)
• S/N Ratio : 56 dB
• Illumination Distance :  30 m (98.43 ft) (IR)
• Illuminator On/Off Control : Auto/Manual
• Illuminator Number : 1 (IR LED)
• Pan/Tilt/Rotation Range  : Pan: 0°–360°  | Tilt: 0°–90° | Rotation: 0°–360°

Lens

• Lens Type : Fixed-focal
• Lens Mount  : M12
• Focal Length  : 2.8 mm; 3.6 mm
• Max. Aperture  : 2.8 mm: F2.0 | 3.6 mm: F2.0
• Field of View : 2.8 mm: Horizontal: 106°; Vertical: 56°; Diagonal: 125° | .6 mm: Horizontal: 92°; Vertical: 48°; Diagonal: 109°
• Iris Control : Fixed
• Close Focus Distance : 2.8 mm: 0.8 m (2.62 ft) | 3.6 mm: 1.3 m (4.27 ft)

Video

• Video Compression : H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
• Smart Codec : Smart H.265+; Smart H.264+
• Video Frame Rate

>Main stream : 2880 × 1620 (1 fps–20 fps) | 2688 × 1520 (1 fps–25/30 fps)

>Sub stream : 704 × 576 (1 fps–25 fps) | 704 × 480 (1 fps–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

• Stream Capability : 2 streams
• Resolution : 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 2560 × 1440(2560 × 1440); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
• Bit Rate Control : CBR/VBR
• Video Bit Rate : H.264: 32 kbps–6144 kbps | H.265: 12 kbps–6144 kbps
• Day/Night : Auto(ICR)/Color/B/W
• BLC : Yes
• HLC : Yes
• WDR : DWDR
• White Balance : Auto; natural; street lamp; outdoor; manual; regional custom
• Gain Control : Auto; manual
• Noise Reduction : 3D NR
• Motion Detection : OFF/ON (4 areas, rectangular)
• Region of Interest (RoI) : Yes (4 areas)
• Smart Illumination : Yes
• Image Rotation : 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
• Mirror :  Yes
• Privacy Masking : 4 areas

Audio

• Built-in MIC : Yes
• Audio Compression : G.711a; G.711Mu; G.726; PCM

Alarm

• Alarm Event : Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception

Network

• Network Port : RJ-45 (10/100 Base-T)
• SDK and API : Yes
• Cyber Security : Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
• Network Protocol : IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast
• Interoperability :ONVIF (Profile S/Profile T); CGI; P2P; Genetec; Milestone
• User/Host : 6 (Total bandwidth: 48 M)
• Storage : FTP
• Browser :IE,Chrome,Firefox
• Management Software : Smart PSS; DSS; DMSS
• Mobile Client : IOS; Android

Certifications

•  CE-LVD: EN62368-1
• CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
• FCC: 47 CFR FCC Part 15, Subpart B

Power

• Power Supply : 12V DC/PoE (802.3af)
• Power Consumption : Basic: 1.9W (12V DC); 2.3W (PoE)
  Max. (ICR + H.265 + max. resolution + main stream + DWDR + IR intensity): 3.9W (12V DC); 4.5W (PoE)

Environment

• Operating Temperature:  –40°C to +60°C (–40°F to +140°F)
• Operating Humidity :  ≤95%
• Storage Temperature : –40°C to +60°C (–40°F to +140°F)
• Protection : IP67

Structure

• Casing : Metal
• Product Dimensions : 162.1 mm × Φ70.1 mm (6.38″ × Φ2.76″)
• Net Weight : 0.32 kg (0.71 lb)
• Gross Weight : 0.45 kg (0.99 lb)
